Our high-quality Solid Brass Flat Washers are meticulously crafted to provide superior performance in a wide range of applications. Made from premium brass alloy, these washers offer an exceptional combination of corrosion resistance, excellent electrical conductivity, and a clean aesthetic. They are an indispensable component for distributing loads, preventing galvanic corrosion, and ensuring stable, long-lasting assemblies.
| Characteristic | Value (Typical) |
|---|---|
| Material | Solid Brass (e.g., C26000, C27000) |
| Type | Flat Washer |
| Standard | DIN 125, ASME B18.22.1, or similar (depending on size) |
| Finish | Plain / Natural Brass |
| Hardness | F40-F60 (Rockwell B, typical) |
| Tensile Strength | 50,000 psi (345 MPa) (typical) |
| Yield Strength | 15,000 psi (105 MPa) (typical) |
| Density | 0.308 lbs/in³ (8.53 g/cm³) |
| Conductivity | ~28% IACS (International Annealed Copper Standard) |
| Nominal Fastener Size | Inner Diameter (ID) | Outer Diameter (OD) | Thickness |
|---|---|---|---|
| M2 | 2.2 mm (0.087 in) | 5.0 mm (0.197 in) | 0.5 mm (0.020 in) |
| M3 | 3.2 mm (0.126 in) | 7.0 mm (0.276 in) | 0.8 mm (0.031 in) |
| M4 | 4.3 mm (0.169 in) | 9.0 mm (0.354 in) | 0.8 mm (0.031 in) |
| M5 | 5.3 mm (0.209 in) | 10.0 mm (0.394 in) | 1.0 mm (0.039 in) |
| #4 (0.112) | 0.125 in (3.18 mm) | 0.250 in (6.35 mm) | 0.020 in (0.51 mm) |
| #6 (0.138) | 0.156 in (3.96 mm) | 0.375 in (9.53 mm) | 0.032 in (0.81 mm) |
| #8 (0.164) | 0.188 in (4.78 mm) | 0.438 in (11.13 mm) | 0.032 in (0.81 mm) |
| 1/4" (0.250) | 0.281 in (7.14 mm) | 0.625 in (15.88 mm) | 0.049 in (1.24 mm) |
| 3/8" (0.375) | 0.406 in (10.31 mm) | 0.875 in (22.23 mm) | 0.065 in (1.65 mm) |
| 1/2" (0.500) | 0.531 in (13.49 mm) | 1.062 in (26.97 mm) | 0.083 in (2.11 mm) |
| All dimensions are nominal and subject to industry standard manufacturing tolerances. |
When your project demands a fastener accessory that combines superb corrosion resistance, reliable electrical conductivity, and a clean finish, our solid brass flat washers are the optimal choice. We ensure that our washers meet stringent quality standards, providing you with dependable performance for your most critical applications. Invest in quality that lasts and performs.
