Unleash Precision & Durability: Advanced PCD Strips & Devices

Elevate Your Machining Performance with Polycrystalline Diamond

In the demanding world of modern manufacturing, where precision, efficiency, and tool longevity are paramount, Polycrystalline Diamond (PCD) stands as the ultimate material solution. We specialize in providing high-performance PCD Strips and meticulously engineered PCD Devices, offering unparalleled hardness, wear resistance, and thermal conductivity for the most challenging machining applications.

Our PCD products are designed to empower tool manufacturers and end-users to achieve superior results in machining non-ferrous metals, composites, plastics, ceramics, and other highly abrasive materials.

What is Polycrystalline Diamond (PCD)?

PCD is a synthetic, extremely hard composite material manufactured by sintering together selected diamond particles at high temperatures and pressures, in the presence of a metallic binder. This process creates a robust, inter-grown structure with uniform diamond distribution, resulting in a material with properties far superior to conventional carbides, even in the most aggressive machining environments.

PCD Strips: The Foundation of Superior Tooling

PCD Strips serve as the raw, high-performance material for creating custom cutting tools. These strips provide maximum flexibility for tool designers and manufacturers to integrate PCD into complex tool geometries, ensuring optimal performance for specific applications.

Key Features of Our PCD Strips:

• Exceptional Hardness & Wear Resistance: Outlasts traditional carbide tooling by significant margins, reducing tool changeovers and downtime.
• High Thermal Conductivity: Efficiently dissipates heat from the cutting zone, prolonging tool life and improving workpiece quality.
• Variety of Grades: Available in a range of diamond particle sizes (fine, medium, coarse) to suit diverse material applications and surface finish requirements.
• Consistent Quality: Manufactured under stringent quality control to ensure uniform diamond distribution and structural integrity across every strip.
• Excellent Brazing Characteristics: Engineered for reliable and strong brazing onto carbide tool bodies, forming a cohesive and durable cutting edge.
• Customizable Dimensions: Offered in various thicknesses, widths, and lengths to accommodate a wide array of tool designs.

Ideal For Manufacturing:

• Reamers, drills, end mills
• Turning and milling inserts
• Woodworking tools
• Jewelry manufacturing tools
• Wear parts and dies

PCD Devices: Pre-Engineered for Precision

PCD Devices are pre-sintered blanks, tips, or inserts, often comprising a layer of PCD precisely bonded to a carbide substrate. These devices simplify tool fabrication, providing ready-to-use cutting edges that can be brazed onto tool holders and ground to final specifications.

Key Features of Our PCD Devices:

• Optimized Geometries: Available in standard shapes (round, square, triangular) and custom designs, ready for final grinding into specific cutting tools.
• Superior Bonding Integrity: Our advanced sintering processes ensure a strong, reliable metallurgical bond between the PCD layer and the tungsten carbide substrate, preventing delamination.
• High Precision: Manufactured with tight tolerances, reducing the need for extensive post-processing and ensuring consistent tool performance.
• Enhanced Tool Rigidity: The carbide backing provides excellent shock absorption and strength, crucial for demanding machining operations.
• Versatile Configurations: Can be designed with different PCD layer thicknesses and carbide substrate dimensions to optimize for specific applications.
• Cost-Effective: Reduces material waste and fabrication time for tool manufacturers, leading to more economical tool production.

Common Device Types Include:

• Brazable PCD inserts (ISO standard and custom)
• PCD drill tips
• PCD reamer blanks
• PCD turning tool blanks
• Custom PCD cutting segments

Overarching Benefits of Choosing Our PCD Products

• Significantly Extended Tool Life: Drastically reduces tool changes and machine downtime.
• Superior Surface Finish: Achieves mirror-like finishes, often eliminating secondary finishing operations.
• Higher Material Removal Rates (MRR): Enables faster machining speeds and increased productivity.
• Exceptional Precision & Consistency: Ensures repeatable results and tighter tolerances.
• Cost-Effectiveness: Long-term savings due to reduced tool consumption and increased operational efficiency.
• Reduced Friction: Lower cutting forces lead to less machine wear and reduced energy consumption.

Primary Applications

Our PCD Strips and Devices are indispensable across a multitude of industries and applications, including:

• Aerospace: Machining lightweight alloys (aluminum-lithium), CFRP (Carbon Fiber Reinforced Polymer), GFRP (Glass Fiber Reinforced Polymer), and other composites.
• Automotive: Processing aluminum alloys, cast iron (especially with high silicon content), and powertrain components.
• Electronics: Machining circuit board materials, graphite electrodes, and ceramic components.
• Woodworking: Producing high-quality cuts in MDF, HDF, particle board, laminated flooring, and exotic woods.
• Medical Devices: Precision machining of surgical instruments and implants from specialized alloys.
• Plastics & Composites: Cutting and shaping various thermoplastic and thermoset materials with precision.
• Non-Ferrous Metals: High-speed machining of aluminum, copper, brass, bronze, and magnesium alloys.
• Wear Parts: Manufacturing durable wear pads, guides, and nozzles.

Customization & Technical Support

We understand that every application is unique. Our team of material science and tooling experts is available to provide:

• Consultation: Guiding you in selecting the optimal PCD grade and configuration for your specific material and machining parameters.
• Custom Dimensions & Shapes: Manufacturing PCD Strips and Devices to your exact specifications.
• Technical Data & Performance Insights: Providing comprehensive information to help you maximize your PCD tooling investment.

Why Choose Us?

• Advanced Manufacturing: Utilizing state-of-the-art HPHT (High Pressure High Temperature) synthesis technology.
• Rigorous Quality Control: Every PCD product undergoes strict inspection to guarantee performance and consistency.
• Expertise & Support: Our knowledgeable team is dedicated to helping you find the perfect PCD solution.
• Competitive Pricing: Delivering exceptional value without compromising on quality.
• Reliable Supply Chain: Ensuring timely delivery to keep your production running smoothly.

Request a Quote or Consultation Today!

Unlock the full potential of your machining operations with our premium PCD Strips and Devices. Contact us now to discuss your requirements, request a custom quote, or schedule a technical consultation.
